Four sizes of tine holders are available for the Aercore™ aerators; the choice is determined by the turf's needs:
The Aercore™ models excel in both areas. All of these aerators can pull as many as 30 cores per square foot. The number of holes per square foot is a variable number based on the ground speed of the tractor. Most competitors try to quote high numbers of square feet per hour.
Serviceability is a key issue on aeration equipment, and the Aercore 1000, 1500, and 2000 have the best service access in the industry. As the photo illustrates, with the cover lifted up, the drive assembly is readily accessed.
The entire tine ram assembly can be removed in a matter of minutes by removing a single cap screw on the top end and four bolts on the rear frame. Tines can easily be changed from the rear of the machine in minutes, as well.
Access to the tine holders is also achieved from the rear of the machine, making it very convenient to alter the hole spacing with a different set of tine holders. Belt changes can be easily accomplished because they are readily accessible.
The Aercore™ 2000, 1500, and 1000 use the same belt-driven design, which provides a quiet, smooth operation that does not require lubrication. A matched pair of fiberglass-reinforced belts provides long life and requires minimal adjustments.
Even the occasional belt replacement is made easy by having all the belt drive components located on top of the machine, where they are easily accessible. All the drive components are easily located for daily checks and routine maintenance. The entire drive assembly utilizes sealed bearings, so there is no need for daily lubrication.
|Largeur de la machine||101,6 cm (37,5 po)|
|Productivité 2,4 x 2 po||1 859 mètres carrés/heure (20 013 pieds carrés / heure)|
|Taille des louchets||25,4 mm (1 po)|
|Dimensions et poids||392 kg|
Ces caractéristiques sont basées sur les informations disponibles au moment de la publication. Elles peuvent être modifiées sans préavis.
Contactez votre concessionnaire John Deere pour plus d'informations.
